Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Fuel Capacity | 118.9 gal |
|---|---|
| Tire Size | 29.5x25 Radials |
Engine
| Engine Model | 3306 |
|---|---|
| Displacement | 641 in³ |
| Gross Power | 285.0 hp |
Weights
| Total Empty | 48,281 lb |
|---|---|
| Front Axle - empty | 31,866 lb |
| Total Loaded | 108,260 lb |
| Rear Axle - empty | 16,416 lb |
| Front Axle - loaded | 47,635 lb |
| Rear Axle - loaded | 60,625 lb |
Dimensions
| Wheelbase | 196 in |
|---|---|
| Overall Length | 350 in |
| Overall Width | 131 in |
| Overall Height | 134 in |
| Dump Height | 216 in |
Transmission
| Max Speed | 32.4 mph |
|---|---|
| Number of Forward Gears | 5 |
Dump
| Rated Payload | 59,979 lb |
|---|---|
| Capacity - Heaped | 22.50 yd³ |
| Capacity - Struck | 16.49 yd³ |
