Caterpillar
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Fuel Capacity | 118.9 gal |
|---|---|
| Tire Size | front 29.5x25 Radials rear 33.25x29 Radials |
Engine
| Engine Model | 3406 |
|---|---|
| Displacement | 891 in³ |
| Gross Power | 385.0 hp |
Weights
| Total Empty | 61,789 lb |
|---|---|
| Front Axle - empty | 38,310 lb |
| Total Loaded | 141,775 lb |
| Rear Axle - empty | 23,479 lb |
| Front Axle - loaded | 55,292 lb |
| Rear Axle - loaded | 86,483 lb |
Dimensions
| Wheelbase | 192 in |
|---|---|
| Overall Length | 385 in |
| Overall Width | 137 in |
| Overall Height | 141 in |
| Dump Height | 217 in |
Transmission
| Max Speed | 34.2 mph |
|---|---|
| Number of Forward Gears | 4 |
Dump
| Rated Payload | 79,986 lb |
|---|---|
| Capacity - Heaped | 29.30 yd³ |
| Capacity - Struck | 22.20 yd³ |
