Caterpillar
New Holland
D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 34,855 lb |
|---|---|
| Fuel Capacity | 65.0 gal |
Engine
| Engine Model | 3304 |
|---|---|
| Displacement | 427 in³ |
| Gross Power | 125.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 126 in |
| Length of Track on Ground | 124 in |
| Width Over Tracks | 120 in |
| Length w/ Blade | 209 in |
| Length w/o Blade | 163 in |
Transmission
| Max Speed - Forward | 6.3 mph |
|---|---|
| Max Speed - Reverse | 7.8 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 85 in |
| Number of Track Rollers per Side | 8 |
| Standard Shoe Size | 34 in |
| Ground Contact Area | 8,324 in³ |
Standard Blade
| Width | 157 in |
|---|---|
| Height | 40 in |
| Capacity | 4.20 yd³ |
| Blade Angle (both directions) | 25 ° |
