Caterpillar
New Holland
D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 32,981 lb |
|---|---|
| Fuel Capacity | 78.0 gal |
Engine
| Engine Model | 3306 |
|---|---|
| Displacement | 641 in³ |
| Gross Power | 155.0 hp |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 106 in |
| Width Over Tracks | 97 in |
| Length w/ Blade | 190 in |
| Length w/o Blade | 148 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Max Speed - Reverse | 8.1 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 7 |
| Standard Shoe Size | 20 in |
| Ground Contact Area | 4,216 in³ |
Standard Blade
| Width | 126 in |
|---|---|
| Height | 45 in |
| Capacity | 4.30 yd³ |
| Blade Angle (both directions) | 12 ° |
