Caterpillar
IT62H
- Operating Weight
- 42,770 lb
- Bucket Capacity - heaped
- 4.30 yd³
- Gross Power
- 230.0 hp
- Net Power
- 211.0 hp
1 / 5
Image 1 of 5
Specifications
88 data points
Operating Specifications
| Operating Weight | 42,770 lb |
|---|---|
| Fuel Capacity | 83.0 gal |
| Tire Size | 23.5R25 |
| Hydraulic System Fluid Capacity | 29.0 gal |
| Operating Voltage | 24 V |
| Turning Radius | 265 in |
| Rear Axle Oscillation | 13 ° |
| Alternator Supplied Amperage | 80 A |
| Cooling System Fluid Capacity | 11.0 gal |
| Transmission Fluid Capacity | 9.0 gal |
| Engine Oil Capacity | 7.9 gal |
| Static Tipping Load - Bucket | 29,602 lb |
| Front Diff Fluid Capacity | 9.5 gal |
| Rear Diff Fluid Capacity | 9.5 gal |
| Static Tipping Load - Forks | 20,667 lb |
| Breakout Force | 35,775 lb |
| Static Tipping Load - Material Handler | 16,163 lb |
| Static Tipping Load - Full Turn | 25,860 lb |
| Dump Clearance | 109,647 in |
Engine
| Engine Model | Cat C7 ACERT |
|---|---|
| Displacement | 439 in³ |
| Gross Power | 230.0 hp |
| Net Power | 211.0 hp |
| Max Torque | 669 lb-ft |
| Bore | 4 in |
| Stroke | 5 in |
| Gross Power - SAE J1995 | 230.0 hp |
| Net Power - ISO 9249 | 211.0 hp |
| Net Power - SAE J1349 | 209.0 hp |
| Flywheel Power | 211.9 hp |
| Net Power - 80/1269/EEC | 211.0 hp |
| Peak Torque - 1,400 rpm - Net | 669 lb-ft |
Weights
| Operating Weight | 42,770 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 71.0 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 2.6 s |
| Dump Time | 2.1 s |
| Pump Type | Piston pump |
| Hydraulic Cycle Time - Dump | 2.1 s |
| Hydraulic Cycle Time - Total | 10.7 s |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 2.6 s |
| Hydraulic Cycle Time - Raise | 6.0 s |
| Steering System - Pump Type | Piston |
| Pilot System - Pump Output | 71.3 gal/min |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 137 in |
| Wheelbase | 132 in |
| Width Over Tires | 110 in |
| Hinge Pin - Max Height | 162 in |
| Wheel Base | 132 in |
| Reach at Max Height and Dump | 48 in |
| Length w/ Bucket on Ground | 336 in |
| Dump Clearance at Max Lift | 110 in |
| Max Lift Height | 150 in |
| Fork Tine Length | 60 in |
| Length with out Forks on Ground | 360 in |
| Height - Top of Hood | 97 in |
| Hook Reach at Max Lift - standard | 81 in |
| Hook Height at Max Lift - standard | 246 in |
| Hook Height at Max Lift - extended | 300 in |
| Hook Reach at Max Lift - extended | 115 in |
Transmission
| Max Speed - Forward | 23.6 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Forward - 1 | 4.3 mph |
| Reverse - 1 | 4.7 mph |
| Forward - 2 | 8.1 mph |
| Reverse - 2 | 8.6 mph |
| Forward - 3 | 14.0 mph |
| Reverse - 3 | 15.2 mph |
| Forward - 4 | 23.6 mph |
Brakes & Steering
| Brakes | Meets required standards. |
|---|
Bucket
| Bucket Capacity - heaped | 4.30 yd³ |
|---|---|
| Bucket Capacity - struck | 3.51 yd³ |
| Breakout Force | 35,775 lb |
| Bucket Capacities | 5.49 yd³ |
| Maximum Bucket Capacity | 5.49 yd³ |
Service Refill Capacities
| Cooling System | 11.0 gal |
|---|---|
| Transmission | 9.0 gal |
| Crankcase | 7.9 gal |
| Differential - Final Drives - Front | 9.5 gal |
| Differential - Final Drives - Rear | 9.5 gal |
| Hydraulic Tank | 29.0 gal |
| Fuel Tank - Standard | 83.0 gal |
Axles
| Front | Fixed front |
|---|---|
| Maximum Single-Wheel Rise and Fall | 19 in |
