Challenger
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 18,308 lb |
|---|---|
| Fuel Capacity | 158.6 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 15,604 lb |
| Alternator Supplied Amperage | 150 A |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 9.0 gal |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Engine Oil Capacity | 5.1 gal |
Engine
| Engine Model | Endurance 74ETA |
|---|---|
| Displacement | 452 in³ |
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and Aftercooled |
| PTO Power | 200.0 hp |
Hydraulic System
| Pump Flow Capacity | 38.9 gal/min |
|---|---|
| Number of Remote Control Valves | 4 |
| Relief Valve Setting | 2,900 psi |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Wheelbase | 121 in |
| Overall Length | 17 in |
| Overall Width | 119 in |
| Height - Top of ROPS/FOPS | 125 in |
Transmission
| Max Speed | 25.0 mph |
|---|---|
| Transmission Type | Tech Star CVT |
