Clark
New Holland
W110B
Wheel Loader
43 specifications
Clark
45C
- Operating Weight
- 21,392 lb
- Bucket Capacity - heaped
- 1.80 yd³
- Gross Power
- 116.0 hp
- Net Power
- 109.0 hp
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 21,392 lb |
|---|---|
| Fuel Capacity | 39.9 gal |
| Tire Size | 17.5-25 |
| Hydraulic System Fluid Capacity | 31.8 gal |
| Static Tipping Weight | 12,771 lb |
| Operating Voltage | 12 V |
| Turning Radius | 226 in |
| Engine Oil Fluid Capacity | 3.5 gal |
| Rear Axle Oscillation | 18 ° |
| Alternator Supplied Amperage | 70 A |
| Front Axle/Diff Fluid Capacity | 3.0 gal |
| Rear Axle/Diff Fluid Capacity | 3.0 gal |
| Cooling System Fluid Capacity | 9.6 gal |
| Transmission Fluid Capacity | 5.0 gal |
Engine
| Engine Model | 6.354.4 |
|---|---|
| Displacement | 354 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 116.0 hp |
| Net Power | 109.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 33.9 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.5 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 2,500 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 103 in |
| Width Over Tires | 90 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket on Ground | 253 in |
| Hinge Pin - Max Height | 141 in |
Transmission
| Max Speed - Forward | 17.9 mph |
|---|---|
| Max Speed - Reverse | 17.9 mph |
| Transmission Type | clark countershaft powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.80 yd³ |
|---|---|
| Bucket Capacity - struck | 1.50 yd³ |
| Dump Clearance at Max Raise | 108 in |
| Breakout Force | 15,152 lb |
| Bucket Width | 100 in |
