Cukurova
Caterpillar
434E
Backhoe Loader
37 specifications
:quality(50)/59550/2a86e61e-1b20-43eb-94ad-dac76d51ba33.png)
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight 2wd | 15,653 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Hydraulic System Fluid Capacity | 33.1 gal |
| Cooling System Fluid Capacity | 6.1 gal |
| Tire Size Front - 2wd / 4wd | 9.16 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Turning Radius | 217 in |
| Rear Axle Fluid Capacity | 4.5 gal |
| Front Axle Fluid Capacity | 2.5 gal |
Engine
| Engine Model | 4R 1040 |
|---|---|
| Displacement | 254 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 76.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Net Max Torque | 214 lb-ft |
Hydraulic System
| Pump Flow Capacity | 27.8 gal/min |
|---|---|
| Relief Valve Pressure | 3,263 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 89 in |
| Transport Length | 226 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Max Speed - Reverse | 13.3 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Transmission Type | Carraro Powershuttle |
Tires & Wheels
| Rear Tires Size | 16.9-28 |
|---|
Backhoe
| Dig Depth | 158 in |
|---|---|
| Reach From Swivel | 168 in |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Clearance at Max Dump Height | 108 in |
| Bucket Breakout Force | 11,533 lb |
| Bucket Width | 88 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 4 in |
