Cukurova
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 30,093 lb |
|---|---|
| Fuel Capacity | 52.9 gal |
| Tire Size | 20.5 - 25 / 16 PRL3 |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Static Tipping Weight | 33,069 lb |
| Operating Voltage | 24 V |
| Turning Radius | 236 in |
| Engine Oil Fluid Capacity | 5.1 gal |
| Rear Axle Oscillation | 20 ° |
| Alternator Supplied Amperage | 45 A |
| Front Axle/Diff Fluid Capacity | 8.0 gal |
| Rear Axle/Diff Fluid Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 10.1 gal |
| Transmission Fluid Capacity | 6.7 gal |
Engine
| Engine Model | 6068TF275 Stage II |
|---|---|
| Displacement | 415 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 166.3 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 55.5 gal/min |
|---|---|
| Raise Time | 6.3 s |
| Lower Time | 5.1 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 3,336 psi |
| Pump Type | load sensing hydraulic and steering system |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 141 in |
| Wheelbase | 115 in |
| Width Over Tires | 102 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 280 in |
| Hinge Pin - Max Height | 151 in |
Transmission
| Max Speed - Forward | 25.5 mph |
|---|---|
| Max Speed - Reverse | 14.9 mph |
| Transmission Type | ZF Full Powershift electronic autoshift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 107 in |
| Breakout Force | 29,855 lb |
| Bucket Width | 103 in |
