Daewoo
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 5,412 lb |
|---|---|
| Max Speed | 6.7 mph |
| Fuel Capacity | 13.9 gal |
| Tire Size | 10 x 16.5 |
Engine
| Engine Model | 4TNE84 |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 42.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 11.9 gal/min |
|---|
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 77 in |
| Wheelbase | 39 in |
| Width Over Tires | 59 in |
| Reach at Max Lift and Dump | 20 in |
| Length with Bucket | 118 in |
| Clearance at Max Lift and Dump | 86 in |
| Turning Radius from Center - inc bucket | 71 in |
| Turning Radius from Center - machine rear | 58 in |
| Length w/o Bucket | 91 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,301 lb |
| Tipping Angle | 2,910 ° |
| Breakout Force | 2,888 psi |
