Daewoo
Tata Hitachi
EX70
Excavator
39 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 17,637 lb |
|---|---|
| Fuel Capacity | 29.1 gal |
| Hydraulic Pump Flow Capacity | 35.7 gal/min |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Hydraulic System Relief Valve Pressure | 3,980 psi |
| Engine Oil Capacity | 2.6 gal |
| Cooling System Fluid Capacity | 2.7 gal |
| Operating Voltage | 12 V |
| Swing Drive Fluid Capacity | 0.4 gal |
Engine
| Engine Model | 4TNV98-XDB |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 52.3 hp |
| Number of Cylinders | 4 |
| Aspiration | naturally aspirated |
| Torque Measured @ | 1,425 rpm |
| Max Torque | 173 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 104 in |
| Tail Swing Radius | 67 in |
| Width to Outside of Tracks | 88 in |
| Removal Counterweight Clearance | 31 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 70 in |
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 18 in |
| Number of Shoes per Side | 38 |
| Number of Carrier Rollers per Side | 1 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 158 in |
|---|---|
| Max Reach Along Ground | 257 in |
| Max Loading Height | 169 in |
| Max Vertical Wall Digging Depth | 115 in |
| Max Cutting Height | 247 in |
| Shipping Length of Unit | 248 in |
| Shipping Height of Unit | 96 in |
Bucket
| Reference Bucket Capacity | 0.41 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.20 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 175 in |
|---|---|
| Max Vertical Wall Digging Depth | 132 in |
| Max Cutting Height | 256 in |
| Max Loading Height | 179 in |
| Max Reach Along Ground | 271 in |
| Shipping Height of Unit | 127 in |
