Dezzi
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Fuel Capacity | 52.9 gal |
|---|---|
| Tire Size | 26.5R25 |
Engine
| Engine Model | Cummins 6 |
|---|---|
| Net Power | 225.3 hp |
| Max Torque | 520 lb-ft |
Weights
| Total Empty | 37,258 lb |
|---|
Dimensions
| Overall Length | 335 in |
|---|---|
| Overall Width | 118 in |
| Overall Height | 134 in |
Transmission
| Max Speed | 31.1 mph |
|---|---|
| Transmission Type | ZF6WG210 |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 55,116 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 17.0 s |
| Capacity - Heaped | 18.40 yd³ |
| Capacity - Struck | 13.11 yd³ |
