Doosan
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 19,246 lb |
|---|---|
| Fuel Capacity | 48.9 gal |
| Tire Size | 17.5-25 |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Static Tipping Weight | 14,330 lb |
| Operating Voltage | 24 V |
| Turning Radius | 212 in |
| Engine Oil Fluid Capacity | 6.9 gal |
| Rear Axle Oscillation | 22 ° |
| Front Axle/Diff Fluid Capacity | 4.0 gal |
| Rear Axle/Diff Fluid Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 11.7 gal |
| Transmission Fluid Capacity | 5.3 gal |
Engine
| Engine Model | QSB4.5 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 108.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
Hydraulic System
| Pump Flow Capacity | 46.5 gal/min |
|---|---|
| Raise Time | 5.5 s |
| Lower Time | 3.3 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 2,901 psi |
| Pump Type | 2x gear |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 107 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 257 in |
| Hinge Pin - Max Height | 143 in |
Transmission
| Max Speed - Forward | 21.1 mph |
|---|---|
| Max Speed - Reverse | 13.5 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.11 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Bucket Width | 97 in |
