Doosan
Case
CX80
Excavator
33 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 30,314 lb |
|---|---|
| Fuel Capacity | 74.0 gal |
| Hydraulic Pump Flow Capacity | 82.5 gal/min |
| Hydraulic System Fluid Capacity | 41.0 gal |
| Hydraulic System Relief Valve Pressure | 4,699 psi |
| Engine Oil Capacity | 5.9 gal |
| Cooling System Fluid Capacity | 5.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 60 A |
| Tire Size | 10.00-20-14PR |
Engine
| Engine Model | DL06 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 132.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged with air to air intercooler |
| Torque Measured @ | 1,400 rpm |
| Net Torque | 384 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 110 in |
| Overall Width | 8 in |
| Upper Structure Clearance | 48 in |
Transmission
| Max Travel Speed | 23.0 mph |
|---|---|
| Transmission Type | hydrostatic powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 180 in |
|---|---|
| Max Reach Along Ground | 296 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 181 in |
|---|---|
| Max Cutting Height | 320 in |
| Max Loading Height | 229 in |
| Shipping Length of Unit | 285 in |
| Shipping Height of Unit | 132 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 295 in |
|---|---|
| Max Cutting Height | 330 in |
| Max Loading Height | 239 in |
| Shipping Height of Unit | 127 in |
| Shipping Length of Unit | 308 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 205 in |
|---|---|
| Max Cutting Height | 349 in |
| Max Loading Height | 256 in |
| Shipping Height of Unit | 137 in |
| Shipping Length of Unit | 295 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 202 in |
|---|---|
| Max Cutting Height | 359 in |
| Max Loading Height | 264 in |
| Shipping Height of Unit | 144 in |
| Shipping Length of Unit | 277 in |
