Doosan
Hitachi
ZX110
Excavator
54 specifications
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 39,242 lb |
|---|---|
| Fuel Capacity | 81.9 gal |
| Hydraulic Pump Flow Capacity | 105.7 gal/min |
| Hydraulic System Fluid Capacity | 54.2 gal |
| Hydraulic System Relief Valve Pressure | 4,697 psi |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 60 A |
| Tire Size | 10.0-20-14PR |
Engine
| Engine Model | DL06 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 156.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged and air to air intercooler |
| Torque Measured @ | 1,400 rpm |
| Net Torque | 506 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 107 in |
| Overall Width | 8 in |
| Upper Structure Clearance | 49 in |
Transmission
| Max Travel Speed | 22.4 mph |
|---|---|
| Transmission Type | hydrostatic powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 235 in |
|---|---|
| Max Reach Along Ground | 362 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.10 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 220 in |
|---|---|
| Max Cutting Height | 360 in |
| Max Loading Height | 253 in |
| Shipping Length of Unit | 343 in |
| Shipping Height of Unit | 127 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 235 in |
|---|---|
| Max Cutting Height | 369 in |
| Max Loading Height | 263 in |
| Shipping Height of Unit | 131 in |
| Shipping Length of Unit | 342 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 256 in |
|---|---|
| Max Cutting Height | 366 in |
| Max Loading Height | 263 in |
| Shipping Height of Unit | 149 in |
| Shipping Length of Unit | 336 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 221 in |
|---|---|
| Max Cutting Height | 404 in |
| Max Loading Height | 293 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 349 in |
