624K Z-Bar
Wheel Loader
48 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 24,251 lb |
|---|---|
| Fuel Capacity | 68.7 gal |
| Tire Size | 17.5x25-12PR (L2) |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Operating Voltage | 24 V |
| Turning Radius | 196 in |
| Rear Axle Oscillation | 11 ° |
| Alternator Supplied Amperage | 50 A |
| Cooling System Fluid Capacity | 8.2 gal |
| Transmission Fluid Capacity | 8.0 gal |
| Engine Oil Capacity | 5.6 gal |
| Static Tipping Load - Bucket | 17,637 lb |
| Front Diff Fluid Capacity | 5.3 gal |
| Rear Diff Fluid Capacity | 5.3 gal |
Engine
| Engine Model | DB58Ti |
|---|---|
| Displacement | 353 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 143.0 hp |
| Net Power | 138.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbo after cooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 412 lb-ft |
Hydraulic System
| Raise Time | 5.0 s |
|---|---|
| Lower Time | 3.3 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 2,845 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 115 in |
| Width Over Tires | 94 in |
| Dump Clearance at Max Lift | 107 in |
| Length w/ Bucket on Ground | 287 in |
| Reach at Max Height and Dump | 42 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 14.6 mph |
| Transmission Type | auto power-shift countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - struck | 2.39 yd³ |
|---|---|
| Breakout Force | 23,800 lb |
