Doosan

SOLAR 140W-V

Excavator

Operating Weight
28,440 lb
Net Power
128.0 hp
All excavators
Doosan SOLAR 140W-V Excavator
1 / 5
Image 1 of 5
Image: lectura-specs.com

Specifications

49 data points

Operating Specifications

Operating Specifications specifications
Operating Weight28,440 lb
Fuel Capacity74.0 gal
Hydraulic Pump Flow Capacity85.6 gal/min
Hydraulic System Fluid Capacity44.4 gal
Hydraulic System Relief Valve Pressure4,978 psi
Engine Oil Capacity5.1 gal
Cooling System Fluid Capacity8.2 gal
Operating Voltage24 V
Tire Size9.00-20-14PR(OTR)

Engine

Engine specifications
Engine ModelDB 58TIS
Displacement353 in³
Power Measured @2,200 rpm
Net Power128.0 hp
Number of Cylinders6
Torque Measured @1,600 rpm
Net Torque362 lb-ft

Dimensions

Dimensions specifications
Ground Clearance15 in
Height - Top of Cab124 in
Wheelbase110 in
Overall Width8 in
Upper Structure Clearance49 in

Transmission

Transmission specifications
Max Travel Speed23.0 mph
Transmission Typehydrostatic powershift
Number of Forward Gears2
Number of Reverse Gears2

Bucket

Bucket specifications
Reference Bucket Capacity0.60 yd³
Maximum Bucket Capacity0.90 yd³
Minimum Bucket Capacity0.30 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed13 rpm

Boom/Stick Mobile Excavator Option 1

Boom/Stick Mobile Excavator Option 1 specifications
Max Digging Depth182 in
Max Cutting Height317 in
Max Reach Along Ground288 in
Max Loading Height222 in
Max Vertical Wall Dig Depth162 in

Boom/Stick Mobile Excavator Option 2

Boom/Stick Mobile Excavator Option 2 specifications
Max Digging Depth174 in
Max Cutting Height317 in
Max Reach Along Ground288 in
Max Loading Height222 in
Max Vertical Wall Dig Depth162 in

Boom/Stick Mobile Excavator Option 3

Boom/Stick Mobile Excavator Option 3 specifications
Max Digging Depth189 in
Max Cutting Height315 in
Max Reach Along Ground294 in
Max Loading Height227 in
Max Vertical Wall Dig Depth169 in

Boom/Stick Mobile Excavator Option 4

Boom/Stick Mobile Excavator Option 4 specifications
Max Digging Depth198 in
Max Cutting Height330 in
Max Reach Along Ground305 in
Max Loading Height235 in
Max Vertical Wall Dig Depth185 in
