Dressta

RD200C

Motor Grader

Max Power
178.0 hp
Net Power Gear 5-6
178.0 hp
All motor graders
Dressta RD200C Motor Grader
1 / 5
Image 1 of 5
Image: speceps.com

Specifications

47 data points

Operating Specifications

Operating Specifications specifications
Std Operation Weight - Total80,195 lb
Tire Size14.00 - 24 G-2 16PR
Fuel Capacity100.4 gal
Hydraulic System Fluid Capacity34.4 gal
Tandem Case Fluid Capacity (each)8.0 gal
Operating Voltage24 V
Cooling System Fluid Capacity10.6 gal
Alternator Supplied Amperage75 A
Transmission Fluid Capacity9.3 gal
Rear Diff/Final Drive Fluid Capacity2.0 gal

Engine

Engine specifications
Engine ModelQSB 6.7
Displacement409 in³
Power Measured @2,400 rpm
Number of Cylinders6
Aspirationturbocharged and CAC
Torque Measured @1,500 rpm
Max Power178.0 hp
Net Power Gear 5-6178.0 hp
Net Torque Gears 5-6685 lb-ft

Hydraulic System

Hydraulic System specifications
Pump Flow21.2 gal/min
Pump Typeaxial piston pump
Relief Valve Pressure2,031 psi

Dimensions

Dimensions specifications
Wheelbase288 in
Overall Length376 in
Width Over Tires100 in
Height to Top of Isomount Cab131 in
Blade Base121 in
Tandem Axle Wheelbase61 in

Transmission

Transmission specifications
Max Speed - Forward27.8 mph
Max Speed - Reverse19.6 mph
Number of Gears - Forward6
Number of Gears - Reverse3
Transmission Typepowershift transmission

Moldboard

Moldboard specifications
Moldboard Height26 in
Moldboard Width145 in
Moldboard Thickness1 in
Side Shift Left32 in
Side Shift Right32 in
Max Depth of Cut14 in

Circle

Circle specifications
Max Lift Above Ground20 in
Diameter53 in
Rotation360 °

Front Axle

Front Axle specifications
Wheel Lean22 °
Oscillation - Total40 °
Ground Clearance23 in

Steering System

Steering System specifications
Turning Radius295,276 in
Articulation Angle25 °
