Dressta

TD-15M

Crawler Dozer

Operating Weight
44,335 lb
Max Speed - Forward
6.3 mph
Gross Power
205.0 hp
Net Power
190.0 hp
All crawler dozers
Dressta TD-15M Crawler Dozer
1 / 5
Image 1 of 5
Image: heavyequipmentguide.ca

Specifications

35 data points

Operating Specifications

Operating Specifications specifications
Operating Weight44,335 lb
Fuel Capacity102.5 gal
Cooling System Fluid Capacity13.2 gal
Final Drives Fluid Capacity10.6 gal
Engine Oil Capacity6.1 gal
Hydraulic Fluid Capacity16.0 gal
Operating Voltage12 V

Engine

Engine specifications
Engine ModelQSC 8.3
Displacement505 in³
Gross Power205.0 hp
Net Power190.0 hp
Number of Cylinders6
AspirationTurbocharged and CAC
Torque Measured @1,500 rpm

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity46.0 gal/min
Relief Valve Pressure2,500 psi
Pump TypePump tandem gear driven from torque converter

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab137 in
Width Over Tracks111 in
Length w/o Blade212 in

Transmission

Transmission specifications
Max Speed - Forward6.3 mph
Max Speed - Reverse7.4 mph
Transmission TypeModular countershaft type power shift electro-hydraulic control
Number of Forward Gears3
Number of Reverse Gears3

Undercarriage

Undercarriage specifications
Ground Pressure11 psi
Number of Track Rollers per Side6
Number of Shoes per Side39
Standard Shoe Size20 in
Ground Contact Area4 in³

Standard Blade

Standard Blade specifications
Width135 in
Height58 in
Capacity7.49 yd³
Blade Angle (both directions)25 °
