Dynapac

CA2800D

Smooth Drum Roller

Operating Weight
30,424 lb
Max Speed
6.3 mph
Drum Width
84 in
Gross Power
130.0 hp
All smooth drum rollers
Dynapac CA2800D Smooth Drum Roller
1 / 5
Image 1 of 5
Image: dynapac.com

Specifications

29 data points

Operating Specifications

Operating Specifications specifications
Operating Weight30,424 lb
Operating weight ROPS26,456 lb
Max Speed6.3 mph
Fuel Capacity272.0 gal
Tire Size231 x 26 AW

Engine

Engine specifications
Engine ModelQSB4.5
Power Measured @2,200 rpm
Gross Power130.0 hp
Engine MakeCummins
Engine TypeWater cooled turbo charged + Intercooler

Dimensions

Dimensions specifications
Ground Clearance18 in
Wheelbase118 in
Overall Length236 in
Height - Top of ROPS/FOPS114 in
Turning Radius - Inside131 in
Gradeability55.0 %
Height114 in
Turning Radius - Outside221 in
Curb clearance18 in
Overhang Rear4 in
Overhang Front4 in

Drum

Drum specifications
Drum Width84 in
Drum Diameter59 in
Nominal Amplitude - High0 in
Centrifugal Force - High56,202 lb
Static Linear Load17 lb-ft
Centrifugal Force - Low29,225 lb
Nominal Amplitude - Low0 in
Drum thickness1 in
