Dynapac
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 30,203 lb |
|---|---|
| Operating weight ROPS | 29,542 lb |
| Max Speed | 7.5 mph |
| Fuel Capacity | 71.9 gal |
| Tire Size | 23.1 x 26 AW |
Engine
| Engine Model | QSB4.5 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 159.6 hp |
| Engine Make | Cummins |
| Engine Type | Water cooled turbo charged + Intercooler |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Wheelbase | 118 in |
| Overall Length | 236 in |
| Height - Top of ROPS/FOPS | 114 in |
| Turning Radius - Inside | 131 in |
| Gradeability | 57.0 % |
| Height | 84 in |
| Turning Radius - Outside | 221 in |
| Curb clearance | 18 in |
| Overhang Rear | 4 in |
| Overhang Front | 4 in |
Drum
| Drum Width | 84 in |
|---|---|
| Drum Diameter | 60 in |
| Centrifugal Force - High | 58,675 lb |
| Static Linear Load | 19 lb-ft |
| Drum thickness | 1 in |
