HD 10 VO
Smooth Drum Roller
40 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 8,600 lb |
|---|---|
| Operating weight ROPS | 8,300 lb |
| Max Speed | 6.0 mph |
| Fuel Capacity | 13.0 gal |
| Engine Oil Capacity | 10.6 gal |
| Steering Angle | 30 ° |
| Water Spray System Fluid Capacity | 53.0 gal |
Engine
| Engine Model | V2203-M |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 45.0 hp |
| Engine Make | Kubota |
| Engine Type | Water cooled |
| Emissions Certification | Tier 4i |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 108 in |
| Wheelbase | 76 in |
| Overall Length | 107 in |
| Overall Width | 50 in |
| Turning Radius - Inside | 120 in |
| Gradeability | 37.0 % |
| Turning Radius - Outside | 168 in |
| Curb clearance | 24 in |
| Overhang Rear | 2 in |
| Overhang Front | 2 in |
Brakes & Steering
| Service brake | Hydrostatic in forward and reverse lever |
|---|---|
| Parking brake | Failsafe multidisc brake on drum and wheels |
Tires & Wheels
| Wheel Track/Tire Overlap | 5 in |
|---|---|
| Track widths | 9 in |
Drum
| Drum Width | 51 in |
|---|---|
| Drum Diameter | 32 in |
| Vibration Frequency 1 | 53 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 8,100 lb |
| Static Linear Load | 7 lb-ft |
| Drum thickness | 1 in |
