BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 23,590 lb |
|---|---|
| Operating weight ROPS | 22,046 lb |
| Max Speed | 7.5 mph |
| Fuel Capacity | 198.2 gal |
| Oscillating angle | 7 ° |
| Steering Angle | 32 ° |
Engine
| Engine Model | TCD 3.6 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 100.6 hp |
| Engine Make | Deutz |
| Engine Type | Water cooled turbo Diesel |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 132 in |
| Overall Length | 177 in |
| Overall Width | 80 in |
| Gradeability | 37.0 % |
| Turning Radius - Outside | 264 in |
| Curb clearance | 28 in |
Drum
| Drum Width | 68 in |
|---|---|
| Drum Diameter | 45 in |
| Vibration Frequency 1 | 48 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 20,233 lb |
| Vibration Frequency 2 | 67 vpm |
| Centrifugal Force - Low | 16,861 lb |
| Nominal Amplitude - Low | 0 in |
| Drum thickness | 1 in |
