Dynapac

CC4200 VI

Smooth Drum Roller

Operating Weight
28,991 lb
Max Speed
7.5 mph
Drum Width
66 in
Gross Power
130.1 hp
All smooth drum rollers
Dynapac CC4200 VI Smooth Drum Roller
1 / 5
Image 1 of 5
Image: stephensonused.com

Specifications

37 data points

Operating Specifications

Operating Specifications specifications
Operating Weight28,991 lb
Operating weight ROPS22,046 lb
Max Speed7.5 mph
Fuel Capacity47.6 gal
Water Spray Tank Fluid Capacity195.5 gal
Oscillating angle7 °
Steering Angle32 °
DEF tank capacity4.0 gal

Engine

Engine specifications
Engine ModelQSF3.8 IV
Power Measured @2,200 rpm
Gross Power130.1 hp
Engine MakeCummins
Engine TypeWater cooled turbo Diesel with After Cooler

Dimensions

Dimensions specifications
Ground Clearance12 in
Height - Top of Cab119 in
Wheelbase148 in
Overall Length199 in
Overall Width85 in
Turning Radius - Inside221 in
Gradeability40.0 %
Turning Radius - Outside287 in
Curb clearance32 in

General Specifications

General Specifications specifications
Engine typeCummins QSF 3.8 (T4f) — Starting 2024 Model Year
DRUM WIDTH IN. (CM)66 (167) — Starting 2024 Model Year
INSIDE TURN RADIUS IN. (CM)220 (558) — Starting 2024 Model Year
WIDTH IN. (CM)75 (190) — Starting 2024 Model Year
FREQUENCY VPM (HZ)3,060/4,020 (51/67) — Starting 2024 Model Year

Drum

Drum specifications
Drum Width66 in
Drum Diameter51 in
Vibration Frequency 151 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High28,776 lb
Vibration Frequency 267 vpm
Static Linear Load14 lb-ft
Centrifugal Force - Low18,884 lb
Nominal Amplitude - Low0 in
Drum thickness1 in
