BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 21,275 lb |
|---|---|
| Max Speed | 7.5 mph |
| Fuel Capacity | 66.1 gal |
| Water Spray Tank Fluid Capacity | 251.0 gal |
| Oscillating angle | 7 ° |
| Steering Angle | 28 ° |
Engine
| Engine Model | 4R1040TC |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 76.0 hp |
| Engine Make | Kirloskar |
| Engine Type | Turbo charged intercooler BSIII Diesel Engine |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 121 in |
| Wheelbase | 110 in |
| Overall Length | 171 in |
| Overall Width | 74 in |
| Gradeability | 39.0 % |
| Turning Radius - Outside | 257 in |
| Curb clearance | 15 in |
Drum
| Drum Width | 67 in |
|---|---|
| Drum Diameter | 48 in |
| Vibration Frequency 1 | 36 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 29,225 lb |
| Vibration Frequency 2 | 54 vpm |
| Static Linear Load | 13 lb-ft |
| Centrifugal Force - Low | 13,489 lb |
| Nominal Amplitude - Low | 0 in |
| Drum thickness | 1 in |
