BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 25,800 lb |
|---|---|
| Operating weight ROPS | 22,700 lb |
| Max Speed | 7.5 mph |
| Fuel Capacity | 48.0 gal |
| Engine Oil Capacity | 53.0 gal |
| Oscillating angle | 8 ° |
| Steering Angle | 32 ° |
| Water Spray System Fluid Capacity | 224.0 gal |
| DEF tank capacity | 4.0 gal |
Engine
| Engine Model | QSF3.8 IV |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 130.0 hp |
| Engine Make | Cummins |
| Engine Type | Water cooled turbo Diesel with After Cooler |
| Emissions Certification | Tier 4f |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 146 in |
| Overall Length | 197 in |
| Overall Width | 86 in |
| Turning Radius - Inside | 216 in |
| Gradeability | 35.0 % |
| Turning Radius - Outside | 293 in |
| Curb clearance | 32 in |
Brakes & Steering
| Service brake | Hydrostatic in forward and reverse lever |
|---|---|
| Parking brake | Failsafe multidisc brake in drum and wheel motors |
Tires & Wheels
| Wheel Track/Tire Overlap | 18 in |
|---|---|
| Track widths | 13 in |
| Wheel Spacing | 5 in |
Drum
| Drum Width | 77 in |
|---|---|
| Drum Diameter | 51 in |
| Vibration Frequency 1 | 51 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 32,370 lb |
| Vibration Frequency 2 | 67 vpm |
| Static Linear Load | 14 lb-ft |
| Centrifugal Force - Low | 20,910 lb |
| Nominal Amplitude - Low | 0 in |
| Drum thickness | 1 in |
