Dynapac
Caterpillar
CB434D
Smooth Drum Roller
50 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 27,778 lb |
|---|---|
| Max Speed | 7.5 mph |
| Fuel Capacity | 63.5 gal |
Engine
| Engine Model | QSB 4.5 T3 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 125.0 hp |
| Aspiration | water cooled turbo diesel with after cooler |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 119 in |
| Wheelbase | 12 in |
| Overall Length | 16 in |
| Overall Width | 93 in |
Drum
| Drum Width | 84 in |
|---|---|
| Drum Diameter | 51 in |
| Vibration Frequency 1 | 43 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 26,078 lb |
| Vibration Frequency 2 | 62 vpm |
| Centrifugal Force - Low | 13,713 lb |
| Nominal Amplitude - Low | 0 in |
