Dynapac
BOMAG
CR 662 RM
Asphalt Paver
37 specifications
1 / 5
Image 1 of 5
Specifications
17 data points
Operating Specifications
| Operating Weight w/ Screed | 39,683 lb |
|---|---|
| Operating Voltage | 24 V |
Engine
| Engine Model | QSB6.7C-190 |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 197.0 hp |
Dimensions
| Transport Width | 100 in |
|---|---|
| Transport Height | 122 in |
| Tire Size | Front 560/300-390 Rear 13.00R-22.5 |
| Width w/ Hopper Open | 134 in |
| Length w/o Screed | 269 in |
Hopper/Paver
| Paving Width - max | 276 in |
|---|---|
| Paving Speed - max | 1.0 mph |
| Hopper Capacity | 7 lb |
| Travel Speed - max | 10.3 mph |
| Auger Diameter | 15 in |
| Paving Thickness - max | 12 in |
