Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Fuel Capacity | 120.0 gal |
|---|---|
| Cooling System Fluid Capacity | 37.0 gal |
| Hydraulic System Fluid Capacity | 46.0 gal |
| Operating Voltage | 24 V |
| Steering System Fluid Capacity | 25.9 gal |
Engine
| Engine Model | KT 19-C |
|---|---|
| Displacement | 1,147 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 450.6 hp |
| Number of Cylinders | 6 |
| Max Torque | 1,406 lb-ft |
| Stroke | 6 in |
| Bore | 6 in |
Weights
| Loaded Weight | 62,700 lb |
|---|---|
| Weight Distribution Front - loaded | 34.0 % |
| Weight Distribution Rear - loaded | 66.0 % |
| Weight Distribution Front - empty | 50.0 % |
| Weight Distribution Rear - empty | 50.0 % |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Wheelbase | 148 in |
| Overall Length | 324 in |
| Overall Width | 145 in |
| Overall Height | 163 in |
Transmission
| Max Speed | 35.6 mph |
|---|---|
| Transmission Type | Planetary Type |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Dump
| Load Capacity - heaped | 30.50 yd³ |
|---|---|
| Load Capacity - Struck | 22.30 yd³ |
