Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Fuel Capacity | 185.0 gal |
|---|---|
| Tire Size | 21.00-35 (32 PR) E-3 |
| Engine Oil Capacity | 16.0 gal |
| Cooling System Fluid Capacity | 43.0 gal |
| Hydraulic System Fluid Capacity | 65.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 A |
| Steering System Fluid Capacity | 26.0 gal |
| Brake/Hoist System Fluid Capacity | 39.0 gal |
Engine
| Engine Model | 16V-71N |
|---|---|
| Displacement | 1,136 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 608.0 hp |
| Net Power | 576.0 hp |
| Number of Cylinders | 16 |
| Aspiration | Natural |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 1,600 lb-ft |
Weights
| Empty Weight | 77,075 lb |
|---|---|
| Loaded Weight | 177,075 lb |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 166 in |
| Overall Length | 366 in |
| Overall Width | 159 in |
| Overall Height | 141 in |
| Dump Height | 341 in |
| Dump Ground Clearance | 25 in |
Transmission
| Max Speed | 33.5 mph |
|---|---|
| Transmission Type | Planetary |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Dump
| Rated Payload | 100,000 lb |
|---|---|
| Dump Angle | 60 ° |
| Raise Time | 18.0 s |
| Load Capacity - heaped | 41.40 yd³ |
| Load Capacity - Struck | 30.80 yd³ |
