Fendt
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Max Speed | 25.0 mph |
|---|---|
| Transmission Type | 2 Speed Motion Shift |
Engine
| Engine Model | MAN |
|---|---|
| Displacement | 928 in³ |
| Power Measured @ | 1,900 rpm |
| Power | 647.0 hp |
| Emission Tier Level | Tier 4F |
Cleaning System
| Total Cleaning Area | 12,322 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,400 rpm |
| Cleaning Fan Speed - Low | 250 rpm |
| Total Sieve Area-Fixed | 8,370 in³ |
| Cleaning Fan Description | 3 x Impeller Fan |
Feeding
| Feeder Description | 4 Strand |
|---|---|
| Feederhouse Lifting Capacity | 13,000 lb |
Grain Handling
| Grain Tank Capacity | 3,258.2 gal |
|---|---|
| Unloading Speed | 4 bu/sec |
Separating
| Separating Area | 3,720 in³ |
|---|---|
| Discharge Grate Area | 6,293 in³ |
Threshing
| Rotor Length | 24 in |
|---|---|
| Rotor Speed - High | 828 rpm |
| Rotor Speed - Low | 200 rpm |
| Rotor Type | Dual |
| Rotor width | 191 in |
| Rotor Feeder Length | 24 in |
| Rotor Feeder width | 55 in |
| Threshing Area | 2,573 in³ |
Residue Management
| BaseCut Configuration - Knives | 56 |
|---|---|
| BaseCut Configuration - Rows | 4 |
| ShortCut Configuration - Knives | 112 |
| ShortCut Configuration - Rows | 8 |
| Straw Chopper Speed - High | 3,600 rpm |
| Straw Chopper Speed - Low | 850 rpm |
