New Holland
W110B
Wheel Loader
43 specifications
Fiat-Hitachi
FB110.2
- Operating Weight
- 18,431 lb
- Bucket Capacity - heaped
- 1.60 yd³
- Gross Power
- 108.0 hp
- Net Power
- 106.0 hp
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 18,431 lb |
|---|---|
| Fuel Capacity | 34.4 gal |
| Tire Size | 16.9 x 24 (12PR) |
| Hydraulic System Fluid Capacity | 36.2 gal |
| Operating Voltage | 12 V |
| Turning Radius | 205 in |
| Engine Oil Fluid Capacity | 4.3 gal |
| Rear Axle Oscillation | 16 ° |
| Alternator Supplied Amperage | 70 A |
| Front Axle/Diff Fluid Capacity | 4.5 gal |
| Rear Axle/Diff Fluid Capacity | 2.4 gal |
| Cooling System Fluid Capacity | 6.4 gal |
| Transmission Fluid Capacity | 4.8 gal |
Engine
| Engine Model | 5.0 - 450T/PD |
|---|---|
| Displacement | 304 in³ |
| Power Measured @ | 2,070 rpm |
| Gross Power | 108.0 hp |
| Net Power | 106.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 42.3 gal/min |
|---|---|
| Relief Valve Setting | 31 psi |
| Pump Type | Load Sensing |
Dimensions
| Height - Top of Cab | 113 in |
|---|---|
| Wheelbase | 88 in |
| Width Over Tires | 98 in |
| Length with Bucket on Ground | 238 in |
| Hinge Pin - Max Height | 135 in |
Transmission
| Max Speed - Forward | 24.3 mph |
|---|---|
| Max Speed - Reverse | 8.6 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 1.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 107 in |
| Breakout Force | 1,663,586 lb |
| Bucket Width | 94 in |
