Gehl
Wacker Neuson
WL18
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 3,911 lb |
|---|---|
| Fuel Capacity | 6.9 gal |
| Tire Size | 27x10.5-15 |
| Hydraulic System Fluid Capacity | 9.0 gal |
| Static Tipping Weight | 1,929 lb |
| Operating Voltage | 12 V |
| Turning Radius | 83 in |
Engine
| Engine Model | Cat C9.3 |
|---|---|
| Displacement | 568 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 23.3 hp |
| Number of Cylinders | 6 |
| Stroke | 6 in |
| Bore | 5 in |
| Net Power - EEC 80/1269 | 250.0 hp |
| Emissions | U.S. EPA Tier 4 Final/EU Stage IV |
Hydraulic System
| Pump Flow Capacity | 20.9 gal/min |
|---|---|
| Relief Valve Setting | 4,640 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 86 in |
| Wheelbase | 54 in |
| Width Over Tires | 42 in |
| Reach at Max Lift and Dump | 16 in |
| Length with Bucket on Ground | 135 in |
| Hinge Pin - Max Height | 107 in |
Transmission
| Max Speed - Forward | 10.5 mph |
|---|---|
| Max Speed - Reverse | 10.5 mph |
Bucket
| Dump Clearance at Max Raise | 78 in |
|---|---|
| Bucket Width | 44 in |
