Gehl
Wacker Neuson
WL18
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 5,840 lb |
|---|---|
| Fuel Capacity | 15.1 gal |
| Tire Size | 30.5x12.5-16.5 |
| Hydraulic System Fluid Capacity | 6.9 gal |
| Static Tipping Weight | 3,794 lb |
| Operating Voltage | 12 V |
| Turning Radius | 119 in |
Engine
| Engine Model | 3TNV88 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 35.0 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 20.9 gal/min |
|---|---|
| Relief Valve Setting | 5,000 psi |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 90 in |
| Wheelbase | 65 in |
| Width Over Tires | 50 in |
| Reach at Max Lift and Dump | 13 in |
| Length with Bucket on Ground | 159 in |
| Hinge Pin - Max Height | 113 in |
Transmission
| Max Speed - Forward | 11.5 mph |
|---|---|
| Max Speed - Reverse | 11.5 mph |
Bucket
| Dump Clearance at Max Raise | 85 in |
|---|---|
| Bucket Width | 55 in |
