Gehl
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 7,610 lb |
|---|---|
| Fuel Capacity | 18.0 gal |
| Tire Size | 33x15.5-16.5 |
| Hydraulic System Fluid Capacity | 11.1 gal |
| Static Tipping Weight | 5,137 lb |
| Operating Voltage | 12 V |
| Turning Radius | 127 in |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 47.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 31.0 gal/min |
|---|---|
| Relief Valve Setting | 5,940 psi |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 91 in |
| Wheelbase | 70 in |
| Width Over Tires | 55 in |
| Reach at Max Lift and Dump | 18 in |
| Length with Bucket on Ground | 178 in |
| Hinge Pin - Max Height | 121 in |
Transmission
| Max Speed - Forward | 12.4 mph |
|---|---|
| Max Speed - Reverse | 12.4 mph |
Bucket
| Dump Clearance at Max Raise | 91 in |
|---|---|
| Bucket Width | 60 in |
