Gehl
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 10,520 lb |
|---|---|
| Max Speed | 7.5 mph |
| Fuel Capacity | 30.5 gal |
| Hydraulic System Fluid Capacity | 29.1 gal |
| Tire Size | 14.00x17.5 HD |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | B4.5T-99C |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 99.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 29.1 gal/min |
|---|
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 81 in |
| Wheelbase | 55 in |
| Width Over Tires | 81 in |
| Reach at Max Lift and Dump | 38 in |
| Length with Bucket | 162 in |
| Clearance at Max Lift and Dump | 108 in |
| Turning Radius from Center - inc bucket | 51 in |
| Turning Radius from Center - machine rear | 40 in |
| Length w/o Bucket | 122 in |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Operating Load Rating | 3,850 lb |
| Operating Width | 81 in |
