21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 7,055 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| Hydraulic System Fluid Capacity | 17.2 gal |
| Static Tipping Weight | 5,181 lb |
| Operating Voltage | 12 V |
| Turning Radius | 134 in |
| Rear Axle Oscillation | 14 ° |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 39.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,600 rpm |
Hydraulic System
| Pump Flow Capacity | 18.5 gal/min |
|---|---|
| Relief Valve Setting | 3,400 psi |
| Pump Type | gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 93 in |
| Wheelbase | 70 in |
| Width Over Tires | 60 in |
| Reach at Max Lift and Dump | 11 in |
| Length with Bucket on Ground | 182 in |
| Hinge Pin - Max Height | 120 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|
Bucket
| Bucket Capacity - heaped | 1.50 yd³ |
|---|---|
| Dump Clearance at Max Raise | 91 in |
| Breakout Force | 6,137 lb |
