Genie
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Engine
| Engine Model | DSG 423 |
|---|---|
| Gross Power | 75.0 hp |
| Power | 49.0 hp |
| Fuel Type | Gas/LPG |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 88 in |
| Overall Length | 334 in |
| Overall Width | 91 in |
| Turning Radius | 189 in |
| Overall Height - mast lowered | 98 in |
Fluid Capacities
| Auxiliary power unit | 12 V DC |
|---|---|
| Lift capacities | 500 lb |
Performance
| Operating Weight | 14,791 lb |
|---|---|
| Max Speed | 4.8 mph |
| Tire Size | 12-16.5 NHS |
| Hydraulic System Fluid Capacity | 45.0 gal |
| Fuel Capacity | 20.1 gal |
| Below ground reach | 60 in |
| Controls | 12 V DC proportional |
| Drive speed - stowed | 4.8 mph |
| Drive speed - raised | 0.7 mph |
| Turning radius - Axle inside | 79 in |
| Turning radius - Axle outside | 189 in |
Platform
| Max Platform Height | 541 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 36 in |
| Platform Inner Width | 96 in |
| Max Working Height | 619 in |
| Max Horizontal Reach | 438 in |
| Platform Rotation | 160 ° |
