Skyjack
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 120 in |
| Overall Length | 176 in |
| Overall Width | 93 in |
| Turning Radius | 301 in |
| Gradeability | 30.0 % |
| Height w/ Rails | 126 in |
| Height w/o Rails | 91 in |
Performance
| Operating Weight | 15,201 lb |
|---|---|
| Max Speed | 2.0 mph |
| Tire Size | 10 x 16.5 |
| Tire Fill/Type | Air Filled |
| Load capacity | 1,499 lb |
Platform
| Max Platform Height | 600 in |
|---|---|
| Platform Inner Length | 168 in |
| Platform Inner Width | 74 in |
| Max Working Height | 673 in |
| Lift Time | 67.0 s |
| Deck Extension | 60 in |
| Lower Time | 72.0 s |
| Platform Height - Lowered | 79,134 in |
