Hamm

3625 HT

Smooth Drum Roller

Max Speed
10.0 mph
Drum Width
88 in
All smooth drum rollers
Hamm 3625 HT Smooth Drum Roller
1 / 5
Image 1 of 5
Image: machinerytrader.com

Specifications

37 data points

Operating Specifications

Operating Specifications specifications
Operating weight ROPS54,157 lb
Operating weight Cabin54,642 lb
Max Speed10.0 mph
Fuel Capacity76.7 gal
Max Weight55,226 lb
Axle load - front35,527 lb
Axle load - rear19,114 lb

Engine

Engine specifications
Engine ModelTCD 2012 L04 2V
Power Measured @2,300 rpm
Number of Cylinders6
Engine MakeDeutz
Emissions CertificationEU Stage IIIA / EPA Tier 3
Engine Power - ISO 14396207.9 hp
Engine power@SAEJ1349207.9 hp

Dimensions

Dimensions specifications
Ground Clearance17 in
Height - Top of Cab121 in
Wheelbase127 in
Overall Length250 in
Turning Radius - Inside196 in
Loadover height94 in
Angle of driving slope-Rear27 °
Angle of driving slope-Front32 °
Width over cab98 in

Drum

Drum specifications
Drum Width88 in
Drum Diameter63 in
Vibration Frequency 125 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High74,412 lb
Vibration Frequency 228 vpm
Static Linear Load34 lb-ft
Centrifugal Force - Low54,629 lb
Nominal Amplitude - Low0 in
Drum thickness2 in
Drum Typesmooth

Steering System

Steering System specifications
Steering MethodArticulated steering
Oscillating angle10 °

Speeds

Speeds specifications
Size of tyres, rearEM 23.5-R25 XTLA
