Hamm
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 23,127 lb |
|---|---|
| Operating weight Cabin | 17,229 lb |
| Fuel Capacity | 39.1 gal |
| Water Spray Tank Fluid Capacity | 208.2 gal |
| Steering Angle | 4 ° |
Engine
| Engine Model | V3307-CR-T |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 99.7 hp |
| Net Power | 98.2 hp |
| Number of Cylinders | 4 |
| Engine Make | KUBOTA |
| Emissions Certification | EPA Tier 4 |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 118 in |
| Overall Length | 163 in |
| Overall Width | 67 in |
| Turning Radius - Inside | 110 in |
| Maximum width | 109,056 in |
Drum
| Drum Width | 59 in |
|---|---|
| Drum Diameter | 45 in |
| Vibration Frequency 1 | 42 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 15,062 lb |
| Vibration Frequency 2 | 50 vpm |
| Static Linear Load | 12 lb-ft |
| Drum thickness | 1 in |
| Drum Type | smooth/divided |
| Oscillation force , rear -1 | 22,031 lb |
| Oscillation frequency , rear - 1 | 36 vpm |
| Tangential amplitude , rear - 1 | 0 in |
Speeds
| Speed - working gear | 6.9 mph |
|---|
