Hamm
Caterpillar
CD44B - Solid Drum
Smooth Drum Roller
33 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 12,434 lb |
|---|---|
| Operating weight ROPS | 9,778 lb |
| Max Speed | 6.9 mph |
| Fuel Capacity | 19.3 gal |
| Water Spray Tank Fluid Capacity | 75.3 gal |
| Oscillating angle | 8 ° |
Engine
| Engine Model | V2203 |
|---|---|
| Power Measured @ | 2,700 rpm |
| Gross Power | 46.4 hp |
| Net Power | 46.4 hp |
| Number of Cylinders | 4 |
| Engine Make | KUBOTA |
| Emission Tier Level | EU Stage IIIA |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Height - Top of Cab | 108 in |
| Wheelbase | 77 in |
| Overall Length | 114 in |
| Overall Width | 60 in |
| Height - Top of ROPS/FOPS | 102 in |
| Turning Radius - Inside | 104 in |
Drum
| Drum Width | 54 in |
|---|---|
| Drum Diameter | 35 in |
| Vibration Frequency 1 | 60 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 14,388 lb |
| Vibration Frequency 2 | 51 vpm |
| Static Linear Load | 7 lb-ft |
| Centrifugal Force - Low | 8,768 lb |
| Nominal Amplitude - Low | 0 in |
| Drum thickness | 1 in |
| Oscillation force , rear -1 | 16,186 lb |
| Oscillation frequency , rear - 1 | 39 vpm |
| Tangential amplitude , rear - 1 | 0 in |
| Oscillation force , rear -2 | 9,667 lb |
| Oscillation frequency , rear - 2 | 30 vpm |
| Tangential amplitude , rear - 2 | 0 in |
