Hamm

HD O75 V

Smooth Drum Roller

Operating Weight
22,928 lb
Max Speed
4.0 mph
Drum Width
66 in
Gross Power
74.3 hp
All smooth drum rollers
Hamm HD O75 V Smooth Drum Roller
1 / 5
Image 1 of 5
Image: keegroup.com.au

Specifications

26 data points

Operating Specifications

Operating Specifications specifications
Operating Weight22,928 lb
Operating weight ROPS16,965 lb
Operating weight Cabin17,549 lb
Max Speed4.0 mph
Fuel Capacity37.0 gal
Water Spray Tank Fluid Capacity190.3 gal
Steering Angle10 °

Engine

Engine specifications
Engine ModelTD 2011 L04 W
Gross Power74.3 hp
Net Power74.3 hp
Number of Cylinders4
Engine MakeDEUTZ

Dimensions

Dimensions specifications
Ground Clearance31 in
Height - Top of Cab117 in
Wheelbase126 in
Overall Length171 in
Overall Width71 in
Turning Radius - Inside161 in
Track Width71 in

Drum

Drum specifications
Drum Width66 in
Drum Diameter45 in
Nominal Amplitude - High0 in
Centrifugal Force - High17,310 lb
Centrifugal Force - Low14,163 lb
Nominal Amplitude - Low0 in
Drum thickness1 in
