Hamm
BOMAG
BW 191 ADO-5
Smooth Drum Roller
35 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 27,867 lb |
|---|---|
| Operating weight ROPS | 21,881 lb |
| Operating weight Cabin | 22,256 lb |
| Max Speed | 3.5 mph |
| Fuel Capacity | 45.8 gal |
| Water Spray Tank Fluid Capacity | 220.4 gal |
| Oscillating angle | 10 ° |
| DEF tank capacity | 5.3 gal |
Engine
| Engine Model | TCD 3.6 L4 |
|---|---|
| Power Measured @ | 2,300 rpm |
| Gross Power | 114.0 hp |
| Net Power | 113.9 hp |
| Number of Cylinders | 4 |
| Engine Make | DEUTZ |
| Emission Tier Level | EPA Tier 4 |
Dimensions
| Ground Clearance | 32 in |
|---|---|
| Height - Top of Cab | 118 in |
| Wheelbase | 146 in |
| Overall Length | 193 in |
| Overall Width | 72 in |
| Turning Radius - Inside | 239 in |
General Specifications
| Engine type | DEUTZ TCD 3.6 L4 — Starting 2024 Model Year |
|---|---|
| DRUM WIDTH IN. (CM) | 66.1 (168) — Starting 2024 Model Year |
| INSIDE TURN RADIUS IN. (CM) | 283.2 (605) — Starting 2024 Model Year |
| WIDTH IN. (CM) | 70.9 (180) — Starting 2024 Model Year |
| FREQUENCY HZ | 42/50 — Starting 2024 Model Year |
Drum
| Drum Width | 66 in |
|---|---|
| Drum Diameter | 47 in |
| Vibration Frequency 1 | 42 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 26,977 lb |
| Vibration Frequency 2 | 50 vpm |
| Static Linear Load | 15 lb-ft |
| Centrifugal Force - Low | 22,256 lb |
| Nominal Amplitude - Low | 0 in |
| Drum thickness | 1 in |
| Oscillation force , rear -1 | 28,776 lb |
| Oscillation frequency , rear - 1 | 39 vpm |
| Tangential amplitude , rear - 1 | 0 in |
