Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Fuel Capacity | 264.2 gal |
|---|---|
| Tire Size | 21.00xR35 |
| Engine Oil Capacity | 25.1 gal |
| Cooling System Fluid Capacity | 46.3 gal |
| Hydraulic System Fluid Capacity | 118.9 gal |
| Transmission Fluid Capacity | 19.1 gal |
Engine
| Engine Model | C27 Acert |
|---|---|
| Displacement | 1,648 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 787.0 hp |
| Net Power | 740.0 hp |
| Number of Cylinders | 12 |
Weights
| Total Loaded | 297,624 lb |
|---|
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 309 in |
| Overall Length | 576 in |
| Overall Width | 166 in |
| Overall Height | 172 in |
| Dump Height | 377 in |
| Dump Ground Clearance | 28 in |
Transmission
| Max Speed | 46.8 mph |
|---|---|
| Number of Forward Gears | 7 |
| Number of Reverse Gears | 1 |
Dump
| Rated Payload | 207,235 lb |
|---|---|
| Dump Angle | 55 ° |
| Raise Time | 16.0 s |
| Lower Time | 15.0 s |
| Capacity - Heaped | 64.99 yd³ |
