Haulotte
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Engine
| Gross Power | 32.2 hp |
|---|---|
| Fuel Type | diesel |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 109 in |
| Overall Length | 14 in |
| Overall Width | 89 in |
| Turning Radius | 233 in |
| Height w/ Rails | 118 in |
| Height w/o Rails | 84 in |
Performance
| Operating Weight | 16,094 lb |
|---|---|
| Max Speed | 3.8 mph |
| Tire Size | 10 x 16.5 |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Tire Fill/Type | foam filled |
| Fuel Capacity | 17.2 gal |
Platform
| Max Platform Height | 630 in |
|---|---|
| Max Platform Weight Capacity | 1,102 lb |
| Platform Inner Length | 154 in |
| Platform Inner Width | 71 in |
| Max Working Height | 709 in |
| Lift Time | 60.0 s |
| Deck Extension | 39 in |
| Lower Time | 60.0 s |
