Heli
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 10,803 lb |
|---|---|
| Max Speed | 11.9 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | front 28x9-15 solid tire rear 6.50-10-10PR |
Engine
| Engine Model | 4JG2 |
|---|---|
| Power Measured @ | 2,450 rpm |
| Torque Measured @ | 1,800 rpm |
| Power | 60.3 hp |
| Fuel Type | diesel |
| Torque | 137 lb-ft |
Dimensions
| Ground Clearance | 5 in |
|---|---|
| Wheelbase | 67 in |
| Overall Width | 49 in |
| Turning Radius | 96 in |
| Overall Height - mast lowered | 86 in |
| Length to Fork Face | 107 in |
| Height to Top of Overhead Guard | 83 in |
| Max Fork Height | 119 in |
| Right Angle Stack | 84 in |
Mast
| Load Capacity | 7,716 lb |
|---|---|
| Load Center | 20 in |
| Lift Speed | 0.7 mph |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Max Fork Spread | 40 in |
