Hidromek
Caterpillar
434E
Backhoe Loader
37 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight 4wd | 18,519 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Turning Radius | 204 in |
Engine
| Engine Model | 1104C-44T |
|---|---|
| Displacement | 269 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 100.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 38.4 gal/min |
|---|---|
| Relief Valve Pressure | 3,336 psi |
| Pump Type | Tandem Gear |
Dimensions
| Transport Width | 97 in |
|---|---|
| Transport Length | 240 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Powershift |
Backhoe
| Dig Depth | 175 in |
|---|---|
| Reach From Swivel | 270 in |
| Bucket Dig Force | 11,969 lb |
| Load Height | 145 in |
Loader
| Bucket Capacity | 1.50 yd³ |
|---|---|
| Lift Capacity | 3,627 lb |
| Clearance at Max Dump Height | 103 in |
| Bucket Width | 96 in |
