Hitachi
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Fuel Capacity | 128.2 gal |
|---|---|
| Tire Size | 26.5R25 Radial Earthmover |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | MercedesBenz OM501LA |
|---|---|
| Displacement | 729 in³ |
| Gross Power | 422.0 hp |
| Net Power | 413.0 hp |
| Aspiration | Turbocharged & Intercooled |
| Max Torque | 1,974 lb-ft |
Weights
| Total Empty | 58,920 lb |
|---|---|
| Front Axle - empty | 29,763 lb |
| Total Loaded | 130,570 lb |
| Rear Axle - empty | 14,470 lb |
| Front Axle - loaded | 40,810 lb |
| Rear Axle - loaded | 44,880 lb |
| Center Axle - empty | 14,480 lb |
| Center Axle - loaded | 44,890 lb |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Wheelbase | 215 in |
| Overall Length | 404 in |
| Overall Width | 127 in |
| Overall Height | 146 in |
| Dump Height | 283 in |
| Dump Ground Clearance | 32 in |
Transmission
| Max Speed | 33.6 mph |
|---|---|
| Transmission Type | Allison HD4500R ORS with integral retarder |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Dump
| Rated Payload | 71,650 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 13.0 s |
| Lower Time | 8.0 s |
| Capacity - Heaped | 26.30 yd³ |
| Capacity - Struck | 19.89 yd³ |
