Hitachi
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Fuel Capacity | 169.1 gal |
|---|---|
| Tire Size | 875/65 R29 |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | OM502LA |
|---|---|
| Displacement | 972 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 523.0 hp |
| Net Power | 512.0 hp |
| Number of Cylinders | 8 |
| Aspiration | Turbocharged & Intercooled |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 1,584 lb-ft |
Weights
| Total Empty | 79,565 lb |
|---|---|
| Front Axle - empty | 39,463 lb |
| Total Loaded | 179,655 lb |
| Rear Axle - empty | 20,007 lb |
| Front Axle - loaded | 53,859 lb |
| Rear Axle - loaded | 62,854 lb |
| Center Axle - empty | 20,095 lb |
| Center Axle - loaded | 62,942 lb |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Wheelbase | 215 in |
| Overall Length | 426 in |
| Overall Width | 154 in |
| Overall Height | 169 in |
| Dump Height | 291 in |
| Dump Ground Clearance | 32 in |
Transmission
| Max Speed | 23.9 mph |
|---|---|
| Transmission Type | Allison HD4500R ORS Full automatic planetary transmission with integral retarder |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 1 |
Dump
| Rated Payload | 100,090 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 11.2 s |
| Lower Time | 9.9 s |
| Capacity - Heaped | 36.90 yd³ |
| Capacity - Struck | 28.00 yd³ |
